    CSS610-8G-2S+IN Eight 1G Ethernet ports and two SFP+ ports for 10G fiber connectivity. Portable, powerful and extremely cost-effective – this switch is an instant classic!

    Cloud Smart Switch 610-8G-2S+IN is our answer to the everlasting demand for more power in a small and simple package. It comes with the lightweight SwOS which is easy to configure from your web browser. It gives you all the basic functionality for a managed switch, and more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields.


     Send purchase questions

    Specifications

    Details
    Product code CSS610-8G-2S+IN
    Switch chip model 88E6193X
    Dimensions 200 x 164 x 44 mm
    Operating System SwitchOS Lite
    Storage size 64 KB
    Storage type FLASH
    MTBF Approximately 200'000 hours at 25C
    Tested ambient temperature -20°C to 60°C
    Suggested price $119.00

    Powering

    Details
    Number of DC inputs 2 (DC jack, PoE-IN)
    DC jack input Voltage 12-57 V
    Max power consumption 11 W
    Max power consumption without attachments 5 W
    Cooling type Passive
    PoE in Passive PoE
    PoE in input Voltage 12-57 V

    Ethernet

    Details
    10/100/1000 Ethernet ports 8

    Fiber

    Details
    SFP+ ports 2

    Certification & Approvals

    Details
    Certification CE, EAC, ROHS
    IP IP20

    Included parts

    BrochureOpen
    Quick GuideOpen
    User ManualOpen
    SFP compatibility listOpen
    Declaration of conformityOpen (CE)

    High resolution images

    #
    #
    #

    Switching results

    CSS610-8G-2S+IN
    Mode Configuration 1518 byte 512 byte 64 byte
    kpps Mbps kpps Mbps kpps Mbps
    Switching Non blocking Layer 2 throughput 2,275.7 27,635.9 6,578.9 26,947.4 41,666.7 21,333.3
    Switching Non blocking Layer 2 capacity 2,275.7 55,271.8 6,578.9 53,894.7 41,666.7 42,666.7
    Switching Non blocking Layer 1 throughput 2,275.7 28,000.0 6,578.9 28,000.0 41,666.7 28,000.0
    Switching Non blocking Layer 1 capacity 2,275.7 56,000.0 6,578.9 56,000.0 41,666.7 56,000.0
