Our team has gathered and taken into account your feedback to make a worthy successor of our popular Wireless Wire Dish. Now we are proud to present the best plug-and-play 60 GHz point-to-point link solution to date – the Wireless Wire nRAY. It is a kit of two pre-paired devices that make a secure AES encrypted wireless connection.

It can easily cover a distance of 1500 meters and reach fiber-like speed, and we have made some serious structural improvements. With the latest antenna technologies, this device is very compact, but even more durable than its predecessors.

The new form-factor has been designed with snowy areas in mind – you won’t have to worry about huge chunks of snow getting stuck and messing with the signal. Due to its size and shape, the nRAY also attracts less unwanted attention. Using the special fine-tune adjustment screws, a perfect alignment can be achieved.

The 60 GHz frequency is unaffected by the crowded wireless spectrum, so you can enjoy a smooth connection even in a busy urban environment. A powerful arm64 dual-core CPU running at 1 GHz ensures wire speed throughput in nearly all packet sizes. The included devices are preconfigured to connect automatically, simply point them at one another and power them on! We have included the power supplies, PoE injectors and a handy precision mount for easier alignment - the solidMOUNT. It is an advanced pole mount metal adapter that allows adjustment both vertically and horizontally.

Specifications

Details
Product code	nRAYG-60adpair
Architecture	ARM 64bit
CPU	88F3720
CPU core count	2
CPU nominal frequency	1 GHz
Dimensions	261 x 166 mm
RouterOS license	3
Operating System	RouterOS
Size of RAM	256 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-30°C to 70°C
Suggested price	$298.00

Powering

Details
Number of DC inputs	1 (PoE-IN)
Max power consumption	7 W
Cooling type	Passive
PoE in	802.3af/at
PoE in input Voltage	12-57 V

Ethernet

Details
10/100/1000 Ethernet ports	1

Certification & Approvals

Details
Certification	CE, FCC, IC, EAC, ROHS
IP	55

Included parts

BrochureOpen

Quick GuideOpen

User ManualOpen

RouterOS current release

Download

Selection guide for PtMP linksOpen

Selection guide for PtP linksOpen

RouterOS software manualOpen

Declaration of conformityOpen (CE)

High resolution images

Ethernet test results

nRAYG-60adpair		88F3720 1G one port test
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	81.3	987.3	235.0	962.6	789.9	404.4
Bridging	25 bridge filter rules	81.3	987.3	221.3	906.4	678.3	347.3
Routing	none (fast path)	81.3	987.3	235.0	962.6	790.4	404.7
Routing	25 simple queues	81.3	987.3	235.0	962.6	450.0	230.4
Routing	25 ip filter rules	81.3	987.3	219.8	900.3	219.5	112.4

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
