MikroTik

60 GHz networking is no longer a privilege – with our new Cube Lite60 CPE you can run extremely cost-effective setups in situations with enterprise-level demands: shopping malls, stadiums, industrial parks, busy urban areas and so on. Same price as SXTsq, 4x the distance!

Connect up to eight of these units to a 60 GHz access point, such as our wAP 60G AP or wAP 60Gx3 AP, and enjoy smooth and stable wireless signal without interference from all the 2.4/5 GHz networks.

Cube Lite60 is designed to be less visible than a traditional dish CPE, but make no mistake – it’s still a real powerhouse. The effective point-to-point distance between Cube Lite60 units is up to 800 meters, point-to-multipoint – up to 500 meters.

No need to share frequency with your neighbors – choose 60 GHz, almost like taking a helicopter during a traffic jam!

Specifications

Details
Product code	RBCube-60ad
Architecture	MIPSBE
CPU	QCA9531
CPU core count	1
CPU nominal frequency	650 MHz
License level	3
Size of RAM	64 MB
Storage size	16 MB
Storage type	FLASH
Tested ambient temperature	-30°C to 70°C
Suggested price	$69.00

Powering

Details
PoE in	Passive PoE
PoE in input Voltage	10-28 V
Number of DC inputs	1 (PoE-IN)
Max power consumption	5 W

Ethernet

Details
10/100 Ethernet ports	1

Certification & Approvals

Details
Certification	CE/RED, FCC, IC, EAC, ROHS

Included parts

BrochureOpen

Quick GuideOpen

RouterOS current releaseDownload

Selection guide for PtP linksOpen

Selection guide for PtMP linksOpen

Declaration of conformityOpen (CE)

High resolution images

Ethernet test results

RBCube-60ad		QCA9531 100M one port test
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	8.1	98.4	23.5	96.3	173.6	88.9
Bridging	25 bridge filter rules	8.1	98.4	23.5	96.3	70.9	36.3
Routing	none (fast path)	8.1	98.4	23.5	96.3	160.8	82.3
Routing	25 simple queues	8.1	98.4	23.5	96.3	90.8	46.5
Routing	25 ip filter rules	8.1	98.4	23.5	96.3	43.2	22.1

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
