wAP ax

wAP ax brings fast and reliable Wi-Fi 6 to your countryside getaway or any other challenging environments – like a rural gas station or a bus stop.

ARM
IP 54
Outdoors
PoE
ROS v7
WiFi 6
Dual-band
wAP ax
Product image
Product image
Product image
Product image
Product image thumbnail
Product image thumbnail
Product image thumbnail
Product image thumbnail

wAP ax: Fast and Reliable Wi-Fi 6 for Challenging Environments

wAP ax brings fast and reliable Wi-Fi 6 to your countryside getaway or any other challenging environments – like a rural gas station or a bus stop. wAP’s legendary weatherproof form-factor has been tested for several generations all across the globe, and remains a favorite among MikroTik users for its simplicity and durability.

A mighty dual-band, dual-chain (2x2 MIMO) radio ensures fast and reliable wireless connection both indoors and outdoors.

Wi-Fi 6: More Than Just Speed

Without a doubt – Wi-Fi 6 is much faster in both 2.4 GHz spectrum (speed increase up to 90%!) and 5 GHz spectrum (up to 40% faster!), but there’s so much more to it. Wi-Fi 6 offers significantly improved energy efficiency and security. OWE/WPA3-PSK/WPA3-EAP encryption and management frame protection help prevent all sorts of attacks, like brute-forcing and Deauthentication Attacks.

And, if you have multiple wAP ax devices over a larger area, you’ll enjoy the improved seamless fast transition roaming – your devices will switch to the strongest signal… seamlessly!

Enhanced Hardware for Uninterrupted Connectivity and Simple Management

This compact access point is equipped with a modern dual-core ARM CPU and runs on RouterOS v7, ensuring stable internet and excellent VPN performance across your property. The wAP ax also supports our new CAPsMAN for easy centralized management of multiple devices with just a few clicks.

The device features two Gigabit Ethernet ports, with PoE-in on one for flexible powering options. You can also use the standard DC jack – because we believe in giving you options.

Stealthy Design – Weatherproof and Vandalproof

wAP ax is designed to blend into any environment. Its simple, elegant design doesn’t attract any unwanted attention, making it perfect for busy public spaces or private properties alike. wAP can be securely fixed to any external wall or roof from the inside of the case, and there is an opening at the back of the case for running the Ethernet cable directly through the wall, keeping the setup extra discreet and secure.

Video thumbnail

Specification

Specifications
  • Product code wAPG-5HaxD2HaxD
  • Suggested price $89.00
  • Architecture ARM 32bit
  • CPU IPQ-5010
  • CPU core count 2
  • CPU nominal frequency 800 MHz
  • CPU Threads count 2
  • RouterOS license 4
  • Operating System RouterOS v7
  • Size of RAM 256 MB
  • Storage size 128 MB
  • Storage type NAND
  • MTBF Approximately 100'000 hours at 25C
  • Tested ambient temperature -40°C to 70°C
Wireless capabilities
  • Wireless 2.4 GHz Max data rate 574 Mbit/s
  • Wireless 2.4 GHz Number of chains 2
  • Wireless 2.4 GHz standards 802.11b/g/n/ax
  • Antenna gain dBi for 2.4 GHz 6.9
  • Wireless 2.4 GHz chip model IPQ-5010
  • Wireless 2.4 GHz generation Wi-Fi 6
  • Wireless 5 GHz Max data rate 2400 Mbit/s
  • Wireless 5 GHz Number of chains 2
  • Wireless 5 GHz standards 802.11a/n/ac/ax
  • Antenna gain dBi for 5 GHz 7
  • Wireless 5 GHz chip model QCN-6102
  • Wireless 5 GHz generation Wi-Fi 6
  • WiFi speed AX3000
Ethernet
  • 10/100/1000 Ethernet ports 2
Powering
  • Number of DC inputs 2 (DC jack, PoE-IN)
  • DC jack input Voltage 12-57 V
  • Max power consumption 9 W
  • Max power consumption without attachments 9 W
  • PoE in 802.3af/at
  • Cooling type Passive
  • PoE in input Voltage 18-57 V
Certification & Approvals
  • Certification CE, FCC, IC, EAC, ROHS
  • IP 54
Other
  • CPU temperature monitor Yes
  • PCB temperature monitor Yes
  • Voltage Monitor Yes
Included parts
Note
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
