    hAP ax lite LTE6 Our most affordable LTE home access point - tiny, fast, and strong enough to harvest the power of RouterOS v7!

    Our hAP lite devices have always been about value. The new hAP ax lite LTE6 is no exception – the addition of a built-in LTE modem allows you to cut costs instead of corners like never before!

    There are four Gigabit Ethernet ports. Combined with a speedy dual-core ARM CPU and 256 MB of RAM, you’ve got a solid SOHO router. With mobile connectivity. But the value train doesn’t stop here. As a bonus, we’ve added 2.4 GHz Wi-Fi 6 (802.11ax) wireless and a strong 4.3 dBi dual-chain antenna. It might not be the main feature here, but don’t underestimate it: our latest wireless chips allow you to squeeze the traditional 2.4 GHz wireless spectrum like a lemon! Depending on your overall setup, you can expect an increase in speed of up to 90%!

    The freedom of LTE

    Cable networks can no longer limit you. Mobile internet is there for you – wherever you choose to go. And it will never slow you down! You can reach consistent speeds of up to 300 Mbps with carrier aggregation, as the built-in CAT6 modem allows devices to use multiple bands simultaneously. That is a huge advantage in areas with many LTE users. hAP ax lite LTE6 provides better responsiveness in a crowded environment and higher efficiency for weaker signal situations in the countryside. Depending on the service provider, we have seen Internet speed doubling in rural areas after switching to carrier aggregation!

    We offer significant project discounts and custom branding options on volume orders. The best price on the market becomes even better!

    And don’t let the price fool you. hAP ax lite LTE6 is the real deal. It comes with all the extensive features of RouterOS 7. Our team takes pride in giving you the freedom to push our devices to the limit. Secure VPN tunneling, bandwidth shaping, firewall, user access control – you make the rules here. It’s your life. Your network. And your opportunity to start saving money like never before!

     Send purchase questions

    Specifications

    Details
    Product code L41G-2axD&FG621-EA
    Architecture ARM
    CPU IPQ-5010
    CPU core count 2
    CPU nominal frequency 800 MHz
    Switch chip model MT7531BE
    RouterOS license 4
    Operating System RouterOS v7
    Size of RAM 256 MB
    Storage size 128 MB
    Storage type NAND
    MTBF Approximately 100'000 hours at 25C
    Tested ambient temperature 0°C to 60°C
    Suggested price $99.00

    Wireless capabilities

    Details
    Wireless 2.4 GHz Max data rate 574 Mbit/s
    Wireless 2.4 GHz number of chains 2
    Wireless 2.4 GHz standards 802.11b/g/n/ax
    Antenna gain dBi for 2.4 GHz 4.3
    Wireless 2.4 GHz chip model IPQ-5010
    Wireless 2.4 GHz generation Wi-Fi 6
    WiFi speed AX600

    Mobile

    Details
    3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
    3G bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
    LTE Category 6 (300Mbit/s Downlink, 50Mbit/s Uplink)
    LTE FDD bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz)
    LTE TDD bands 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
    TAC 86335904

    Ethernet

    Details
    10/100/1000 Ethernet ports 4

    Peripherals

    Details
    Number of SIM slots 1 Modem (Micro SIM)

    Powering

    Details
    Number of DC inputs 1 (USB-C)
    Supported Voltage 5 V
    Max power consumption 12 W
    Max power consumption without attachments 12 W
    Cooling type Passive

    Certification & Approvals

    Details
    Certification CE, EAC, ROHS
    IP 20

    Other

    Details
    Mode button Yes

    Included parts

    BrochureOpen
    User ManualOpen
    Block DiagramOpen
    Safety and regulatory informationOpen
    RouterOS software manualOpen
    Declaration of conformityOpen (CE)

    High resolution images

    Ethernet test results

    L41G-2axD&FG621-EAIPQ-5010 all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)202.82462.8373.21528.5396.8215.9
    Bridging25 bridge filter rules173.92112.3175.8719.9181.598.7
    Routingnone (fast path)202.82462.8321.11315.4348.4189.6
    Routing25 simple queues137.41668.1140.2574.4141.977.2
    Routing25 ip filter rules77.9946.575.8310.57641.3
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
