SXT G-5HnD

Gigabit SXT Dual pol antenna Integrated design

Outdoors

PoE

Specification Find retailer

SXT G-5HnD

SXTG-5HnD is a low cost, high speed 5GHz outdoor sector AP, with a Gigabit port, to fully utilize the capacity of 802.11n. At 25° degree beamwidth, you can conveniently create sector setups with a few client devices because this device comes with an AP license (Level4).

Complete with a ready to mount enclosure and built-in 16dBi antenna, the package contains everything you need to make AP, point to point link or CPE.

Package contains SXTG-5HnD, mounting loops, PoE injector, power adapter

SXT install guide:

Specification

Specifications

Product code RBSXTG-5HnD
Suggested price $99.00
Architecture MIPSBE
CPU AR7242
CPU core count 1
CPU nominal frequency 400 MHz
Dimensions 140x140x56mm, 265g
RouterOS license 3
Operating System RouterOS
Size of RAM 32 MB
Storage size 64 MB
Storage type NAND
MTBF Approximately 100'000 hours at 25C
Tested ambient temperature -30C to +70C

Powering

Max power consumption without attachments 7W
PoE in Passive PoE

Wireless specifications

Wireless 5 GHz Max data rate 300 Mbit/s
Wireless 5 GHz Number of chains 2
Wireless 5 GHz standards 802.11a/n
Antenna gain dBi for 5 GHz 16
Wireless 5 GHz chip model AR9280
Wireless 5 GHz generation Wi-Fi 4

Ethernet

10/100/1000 Ethernet ports 1

Peripherals

Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A

Other

PCB temperature monitor Yes
Voltage Monitor Yes
Beeper Yes

Note

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.

RBSXTG-5HnD		AR7242 1G all port test
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	81.2	986.1	178.4	730.9	194.0	99.3
Bridging	25 bridge filter rules	51.5	625.5	52.3	214.3	53.7	27.5
Routing	none (fast path)	81.2	986.1	167.0	684.0	183.7	94.1
Routing	25 simple queues	81.2	986.1	88.5	362.4	92.8	47.5
Routing	25 ip filter rules	37.6	457.0	38.4	157.1	37.5	19.2

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
