Name |
wAP R
|
LtAP mini
|
10/100 Ethernet ports |
1
|
1
|
802.11b |
Yes
|
Yes
|
802.11g |
Yes
|
Yes
|
802.11n |
Yes
|
Yes
|
Antenna gain |
2
|
1.5
|
Antenna header count |
N/A
|
1
|
Architecture |
MIPSBE
|
MIPSBE
|
Automotive input Voltage |
9-30 V
|
N/A
|
CPU |
QCA9531
|
QCA9531
|
CPU core count |
1
|
1
|
CPU nominal frequency |
650 MHz
|
650 MHz
|
Can be used indoors |
Yes
|
Yes
|
Can be used outdoors |
Yes
|
Yes
|
Certification |
CE, FCC, IC, E-MARK, EAC, ROHS
|
CE, FCC, IC, E-MARK, EAC, ROHS
|
Cooling type |
Passive
|
Passive
|
DC jack input Voltage |
9-30 V
|
8-30 V
|
Dimensions |
185x85x30 mm
|
139 x 77 x 28,5 mm
|
GNSS standards |
N/A
|
GPS
|
GPS RF connector type |
N/A
|
uUFL
|
GPS interface model |
N/A
|
MT3337V
|
IP |
IP54
|
IP54
|
MTBF |
Approximately 100'000 hours at 25C
|
Approximately 100'000 hours at 25C
|
Max power consumption |
6 W
|
9 W
|
Max power consumption without attachments |
N/A
|
4 W
|
MicroUSB input Voltage |
N/A
|
5 V
|
MiniPCI-e slots |
1
|
1
|
Mode button |
N/A
|
Yes
|
Number of DC inputs |
3
|
3
|
Number of SIM slots |
1
|
2
|
Operating System |
RouterOS
|
RouterOS
|
PCB temperature monitor |
Yes
|
N/A
|
PoE in |
Passive PoE
|
802.3af/at
|
PoE in input Voltage |
9-30 V
|
12-57 V
|
RouterOS license |
4
|
4
|
SIM port type |
Mini SIM
|
Mini SIM
|
SIM port usage |
Modem
|
Modem
|
Serial console port |
N/A
|
RS232
|
Size of RAM |
64 MB
|
64 MB
|
Storage size |
16 MB
|
16 MB
|
Storage type |
FLASH
|
FLASH
|
TX power |
2.4 GHz | |
---|
| TX | RX | 1MBit/s | 22 | -96 | 11MBit/s | 22 | -89 | 6MBit/s | 20 | -93 | 54MBit/s | 18 | -74 | MCS0 | 20 | -93 | MCS7 | 16 | -71 |
|
2.4 GHz | |
---|
| TX | RX | 1MBit/s | 22 | -96 | 11MBit/s | 22 | -89 | 6MBit/s | 20 | -93 | 54MBit/s | 18 | -74 | MCS0 | 20 | -93 | MCS7 | 16 | -71 |
|
Tested ambient temperature |
-40°C to 60°C
|
-40°C to 70°C
|
Voltage Monitor |
Yes
|
N/A
|
Wi-Fi generation |
Wi-Fi 4
|
Wi-Fi 4
|
Wireless 1 Max data rate |
300 Mbit/s
|
300 Mbit/s
|
Wireless 1 Number of chains |
2
|
2
|
Wireless 1 band |
2.4 GHz
|
2.4 GHz
|
Wireless 1 generation |
Wi-Fi 4
|
Wi-Fi 4
|
Wireless chip model |
QCA9531
|
QCA9531
|
Wireless standards |
802.11b/g/n
|
802.11b/g/n
|
