| Name |
cAP ac
|
NetMetal ac²
|
| 10/100/1000 Ethernet ports |
2
|
1
|
| 802.11a |
Yes
|
Yes
|
| 802.11b |
Yes
|
Yes
|
| 802.11g |
Yes
|
Yes
|
| 802.11n |
Yes
|
Yes
|
| Antenna gain |
2
|
N/A
|
| Antenna gain dBi for Wireless 2 |
2.5
|
N/A
|
| Antenna header count |
N/A
|
3
|
| Architecture |
ARM 32bit
|
ARM 32bit
|
| CPU |
IPQ-4018
|
IPQ-4019
|
| CPU Threads count |
4
|
4
|
| CPU core count |
4
|
4
|
| CPU nominal frequency |
716 MHz
|
716 MHz
|
| Can be used indoors |
Yes
|
N/A
|
| Can be used outdoors |
N/A
|
Yes
|
| Certification |
CE, FCC, IC, EAC, ROHS
|
CE, FCC, IC, EAC, ROHS
|
| Cooling type |
Passive
|
Passive
|
| DC jack input Voltage |
N/A
|
12-57 V
|
| Dimensions |
Round case: ⌀ 136 mm, height: 30 mm; Square case: 145 mm x 145 mm x 30 mm
|
143 x 247 x 48 mm
|
| IP |
20
|
IP66
|
| MTBF |
Approximately 100'000 hours at 25C
|
Approximately 200'000 hours at 25C
|
| Max USB current (A) |
N/A
|
1
|
| Max out per port output (input 18-30 V) |
500 mA
|
N/A
|
| Max out per port output (input 30-57 V) |
400 mA
|
N/A
|
| Max power consumption |
24 W
|
28 W
|
| Max power consumption without attachments |
12 W
|
12 W
|
| Max total out (A) |
500 mA
|
N/A
|
| MiniPCI-e slots |
N/A
|
1
|
| Mode button |
Yes
|
N/A
|
| Number of DC inputs |
1
|
2
|
| Number of SIM slots |
N/A
|
1
|
| Number of USB ports |
N/A
|
1
|
| Operating System |
RouterOS
|
RouterOS
|
| PCB temperature monitor |
N/A
|
Yes
|
| PoE in |
802.3af/at
|
802.3af/at
|
| PoE in input Voltage |
17-57 V
|
24-57 V
|
| PoE out |
Passive PoE up to 57V
|
N/A
|
| PoE-out ports |
Ether2
|
N/A
|
| RouterOS license |
4
|
4
|
| SFP ports |
N/A
|
1
|
| SIM port type |
N/A
|
Micro SIM
|
| SIM port usage |
N/A
|
Modem
|
| Size of RAM |
128 MB
|
256 MB
|
| Storage size |
16 MB
|
16 MB
|
| Storage type |
FLASH
|
FLASH
|
| Switch chip model |
IPQ-4018
|
IPQ-4019
|
| TX power |
| 2.4 GHz | |
|---|
| TX | RX | | 1MBit/s | 26 | -100 | | 11MBit/s | 26 | -94 | | 6MBit/s | 26 | -96 | | 54MBit/s | 23 | -78 | | MCS0 | 26 | -96 | | MCS7 | 22 | -73 | | 5 GHz | |
|---|
| TX | RX | | 6MBit/s | 26 | -96 | | 54MBit/s | 21 | -80 | | MCS0 | 26 | -96 | | MCS7 | 20 | -75 | | MCS9 | 18 | -70 |
|
| 2.4 GHz | |
|---|
| TX | RX | | 1MBit/s | 30 | -100 | | 11MBit/s | 30 | -94 | | 6MBit/s | 30 | -96 | | 54MBit/s | 27 | -80 | | MCS0 | 30 | -96 | | MCS7 | 26 | -75 | | 5 GHz | |
|---|
| TX | RX | | 6MBit/s | 30 | -96 | | 54MBit/s | 27 | -80 | | MCS0 | 30 | -96 | | MCS7 | 26 | -75 | | MCS9 | 23 | -72 |
|
| Tested ambient temperature |
-40°C to 50°C
|
-40°C to 70°C
|
| USB Power Reset |
N/A
|
Yes
|
| USB slot type |
N/A
|
USB type A
|
| Voltage Monitor |
N/A
|
Yes
|
| Wi-Fi generation |
Wi-Fi 5
|
Wi-Fi 5
|
| WiFi speed |
AC1200
|
AC1200
|
| Wireless 1 Max data rate |
300 Mbit/s
|
300 Mbit/s
|
| Wireless 1 Number of chains |
2
|
2
|
| Wireless 1 band |
2.4 GHz
|
2.4 GHz
|
| Wireless 1 generation |
Wi-Fi 4
|
Wi-Fi 4
|
| Wireless 2 Max data rate |
867 Mbit/s
|
867 Mbit/s
|
| Wireless 2 Number of chains |
2
|
2
|
| Wireless 2 band |
5 GHz
|
5 GHz
|
| Wireless 2 generation |
Wi-Fi 5
|
Wi-Fi 5
|
| Wireless chip model |
IPQ-4018
|
IPQ-4019
|
| Wireless secondary chip model |
IPQ-4018
|
IPQ-4019
|
| Wireless secondary standards |
802.11a/n/ac
|
802.11a/n/ac
|
| Wireless standards |
802.11b/g/n
|
802.11b/g/n
|
