MikroTik Routers and Wireless - Products: CCR2116-12G-4S+

We wanted to see the full potential of the good, old, reliable 10G networking combined with a modern CPU. CCR2116-12G-4S+ allows you to forget about CPU limitations in your setup. Like its younger brother – the amazing CCR2004, this router features the mighty Amazon Annapurna Labs Alpine CPU.

But with 16 cores running at 2 GHz, this CCR eats the other one for breakfast. For example, we see at least a 15% increase in single-core performance. And that is the most important aspect when it comes to heavy operations based on per-connection processing. Like queues, for example. CCR2116-12G-4S+ sets a new standard of single-core performance in the whole CCR product family! And it supports Layer 3 Hardware Offloading!

Obviously, you need the right connectivity to harness this power. There are four 10G SFP+ ports. They have a separate, full-duplex line connected to the Marvell Aldrin family switch chip. Then we have Gigabit Ethernet ports. 12 of them are running through the Marvel chip. And there is another Gigabit port connected directly to the CPU. For management purposes.

Each group of 4 ports has a separate full-duplex connection to the switch chip. No bottlenecks here. You can expect switch-like throughput in most setups. The new generation of processors offers mind-blowing performance. If we look at the CCR1036 - the powerhouse with a 36 core CPU, the new CCR2116 can easily double the performance. 16 cores vs 36 cores. Double the performance. Or even more.

If you are a rather large ISP, dealing with dynamic routing, massive BGPs, complex firewall rules, and intricate quality of service configurations..This is the right device for you. Combination of raw power and utility with the reliable 10G networking. And yes, like with any ISP-level device, we’ve included a dual-redundant power supply. So you have one less thing to worry about.

Specifications

Details
Product code	CCR2116-12G-4S+
Architecture	ARM 64bit
CPU	AL73400
CPU core count	16
CPU nominal frequency	2000 MHz
Switch chip model	98DX3255
Dimensions	443 x 199 x 44 mm
RouterOS license	6
Operating System	RouterOS v7
Size of RAM	16 GB
Storage size	128 MB
Storage type	NAND
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-20°C to 60°C
IPsec hardware acceleration	Yes
Suggested price	$995.00

Powering

Details
Number of AC inputs	2
AC input range	100-240
Number of PSU slots	2
Frequency (Hz)	47-63
Max power consumption	83 W
Max power consumption without attachments	60 W
Cooling type	4 fans

Ethernet

Details
10/100/1000 Ethernet ports	13

Fiber

Details
SFP+ ports	4

Peripherals

Details
Serial console port	RJ45
Number of M.2 slots	1

Other

Details
CPU temperature monitor	Yes
PCB temperature monitor	Yes
Voltage Monitor	Yes
Mode button	Yes

Certification & Approvals

Details
Certification	CE, EAC, ROHS

Included parts

BrochureOpen

Quick GuideOpen

User ManualOpen

RouterOS current releaseDownload

Block DiagramOpen

SFP compatibility listOpen

RouterOS software manualOpen

Declaration of conformityOpen (CE)

High resolution images

Ethernet test results

CCR2116-12G-4S+		AL73400 all port test (CCR2116)
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	3204.8	38919.1	9114.6	37333.4	29458.9	16025.6
Bridging	25 bridge filter rules	2662.5	32333.4	2682.2	10986.3	2758.9	1500.8
Routing	none (fast path)	3212.2	39009.0	9125.3	37377.2	28095.6	15284.0
Routing	25 simple queues	3212.2	39009.0	6322.6	25897.4	6300.9	3427.7
Routing	25 ip filter rules	3212.2	39009.0	3927.9	16088.7	3901.5	2122.4
Routing	none (L3HW)	4226.3	51323.7	12218	50045.1	73863.6	40181.8

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

IPsec test results

CCR2116-12G-4S+		AL73400 IPsec throughput
Mode	Configuration	1400 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Single tunnel	AES-128-CBC + SHA1	179.7	2012.6	186.4	763.5	182.8	93.6
256 tunnels	AES-128-CBC + SHA1	366.8	4108.2	667.3	2733.3	668.8	342.4
256 tunnels	AES-128-CBC + SHA256	366.8	4108.2	666.2	2728.8	670.4	343.2
256 tunnels	AES-256-CBC + SHA1	366.2	4101.4	667.6	2734.5	668.8	342.4
256 tunnels	AES-256-CBC + SHA256	366.2	4101.4	670	2744.3	670.4	343.2

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
