    Audience Tri-band (one 2.4 GHz & two 5 GHz) home access point with meshing technology

    Wi-Fi has to be fast, reliable, easy to manage, it must reach every room and every corner. That is exactly what Audience devices can deliver in grand style – even in the biggest houses!

    Audience is a tri-band (one 2.4 GHz & two 5 GHz) home access point with meshing technology. If you need Wi-Fi in a huge building with all kinds of obstacles, simply add more Audience devices to your network – with a press of a button they will sync seamlessly and create a single Wi-Fi network to cover the whole premises. The initial setup is also very simple – download the iOS or Android MikroTik app, it will connect to the router and guide you through a quick setup process.

    In some cases a single Audience unit might be able to replace several other routers – in our tests it covered 1858 m² (20000 square feet) easily. It depends on the amount of obstacles, Wi-Fi clients and interference, so results may vary.

    Dual-chain 2.4 GHz and 5 GHz wireless coverage will solve most interference issues in a crowded environment. For example, you can simultaneously use the 2.4 GHz channel for all your household mobile devices and reserve the 5 GHz channel for your PC or TV.

    Order your Audience today and start living in the future. The future of easy and elegant networking.

     Send purchase questions

    Specifications

    Details
    Product code RBD25G-5HPacQD2HPnD
    Architecture ARM 32bit
    CPU IPQ-4019
    CPU core count 4
    CPU nominal frequency 716 MHz
    License level 4
    Size of RAM 256 MB
    Storage size 128 MB
    Storage type NAND
    Tested ambient temperature -40°C to 60°C
    Suggested price $169.00

    Powering

    Details
    PoE in Passive PoE
    PoE in input Voltage 24-57 V
    Number of DC inputs 2 (DC jack, PoE-IN)
    DC jack input Voltage 12-57 V
    Max power consumption 27 W
    Max power consumption without attachments 27 W

    Wireless

    Details
    Wireless 2.4 GHz Max data rate 300 Mbit/s
    Wireless 2.4 GHz number of chains 2
    Wireless 2.4 GHz standards 802.11b/g/n
    Antenna gain dBi for 2.4 GHz 3.5
    Wireless 2.4 GHz chip model IPQ-4019
    Wireless 2.4 GHz generation Wi-Fi 4

    Wireless 5 GHz Max data rate 867 Mbit/s
    Wireless 5 GHz number of chains 2
    Wireless 5 GHz standards 802.11a/n/ac
    Antenna gain dBi for 5 GHz 4.5
    Wireless 5 GHz chip model IPQ-4019
    Wireless 5 GHz generation Wi-Fi 5

    Wireless 5 GHz Max data rate 1733 Mbit/s
    Wireless 5 GHz number of chains 4
    Wireless 5 GHz standards 802.11a/n/ac
    Antenna gain dBi for 5 GHz 4.5
    Wireless 5 GHz chip model QCA9984
    Wireless 5 GHz generation Wi-Fi 5

    Ethernet

    Details
    10/100/1000 Ethernet ports 2

    Certification & Approvals

    Details
    Certification CE/RED, FCC, IC, EAC, ROHS

    Wireless specifications

    2.4 GHzTransmit (dBm)Receive Sensitivity
    1MBit/s26-100
    11MBit/s26-94
    6MBit/s29-96
    54MBit/s26-80
    MCS029-96
    MCS725-75
    5 GHzTransmit (dBm)Receive Sensitivity
    6MBit/s28-95
    54MBit/s25-78
    MCS028-95
    MCS724-75
    MCS922-70
    5 GHzTransmit (dBm)Receive Sensitivity
    6MBit/s32-96
    54MBit/s28-80
    MCS032-96
    MCS727-77
    MCS925-72

    Included parts

    BrochureOpen
    Quick GuideOpen
    RouterOS current releaseDownload
    Block DiagramOpen
    Declaration of conformityOpen (CE)

    High resolution images

    Ethernet test results

    RBD25G-5HPacQD2HPnDIPQ-4019 1G all port test
    ModeConfiguration1518 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Bridgingnone (fast path)162,51973.4469,91924.71488,4762.1
    Bridging25 bridge filter rules162,51973.4351,21438.5352,1180.3
    Routingnone (fast path)162,51973.4469,91924.71488,4762.1
    Routing25 simple queues162,51973.4468,61919.4493,4252.6
    Routing25 ip filter rules162,51973.4222,8912.6227,4116.4
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
    3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    IPsec test results

    RBD25G-5HPacQD2HPnDIPQ-4018 IPsec throughput
    ModeConfiguration1400 byte512 byte64 byte
    kppsMbpskppsMbpskppsMbps
    Single tunnelAES-128-CBC + SHA137.9424.559241.761.631.5
    256 tunnelsAES-128-CBC + SHA136403.238.5157.739.820.4
    256 tunnelsAES-128-CBC + SHA25636403.238.5157.739.820.4
    256 tunnelsAES-256-CBC + SHA134.4385.337.9155.239.820.4
    256 tunnelsAES-256-CBC + SHA25634.4385.337.9155.239.820.4
    1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
    2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
    3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
